Cisco ASR 1000 Series Hardware Installation Guide

A-3
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Appendix A Cisco ASR 1000 Series Router Specifications
Cisco ASR 1006 Router Specifications
Cisco ASR 1006 Router MGMT Ethernet Port Pinouts
Table A-3 lists the RJ-45 port pinout for the front panel Management Ethernet port.
Cisco ASR 1006 Router BITS Port Signals and Pinouts
Table A-4 lists the pinouts of the Building Integrated Timing Supply (BITS) RJ45 port on the Cisco
ASR 1006 Router.
Table A-5 lists the pinouts of the Building Integrated Timing Supply (BITS) and the DOCSIS Timing
Interface (DTI) RJ45 port on the Cisco ASR1000-RP2 front panel.
Table A-3 RJ-45 Management Ethernet Port Pinouts
Pin Signal Direction Description
1 TX Data+ Out Transmit Data
2 TX Data– Out Transmit Data
3 RX Data+ In Receive Data
4, 5 NC — —
6 RX Data– In Receive Data
7,8 NC — —
Table A-4 BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP1
Pin Signal Direction Description
1 RX Ring Input Receive Ring
2 RX Input Receive (T1/E1)
3, 4 N/C — —
5 TX Ring Unused —
6 TX Unused —
7,8 N/C — —
Table A-5 BITS RJ-45 Receptacle Pinouts for Cisco ASR1000-RP2
Pin Signal Direction Description
1 RX Ring Input/Bi (DTI) Receive Ring/Bidirectional DTI
2 RX TIP Input/Bi (DTI) Receive TIP (T1/E1) Bidirectional DTI
3, 4 N/C — —
5 TX Ring Output Transmit Ring/Bidirectional DTI
6 TX Output Transmit TIP (T1/E1) Bidirectional DTI
7,8 N/C — —
