Cisco ASR 1000 Series Hardware Installation Guide

A-5
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Appendix A Cisco ASR 1000 Series Router Specifications
Cisco ASR 1004 Router Specifications
closed pin. The connections that describe alarm activity are Alarm off (Common is connected to
normally closed and normally open is disconnected) and Alarm on (Common is connected to normally
open and normally closed is disconnected).
Table A-8 lists the common, normally open, and normally closed relay contacts accessible to an external
alarm monitoring facility by means of the DB-25 connector.
Cisco ASR 1004 Router Specifications
This section lists the specifications for the Cisco ASR 1004 Router.
Table A-9 lists the Cisco ASR 1004 Router physical specifications.
Table A-8 Cisco ASR 1006 Router DB-25 Alarm Connector Pinout Assignments
Signal Description
Common
(CM)
Normally
Open (NO)
Normally
Closed (NC) SPARE
CRTAA Critical Audible Alarm 2 1 14 —
MAJAA
Major Audible Alarm
16 3 15 —
MINAA
Minor Audible Alarm
54 17 —
CRTVA
Critical Visual Alarm
19 6 18 —
MAJVA
Major Visual Alarm
87 20 —
MINVA
Minor Visual Alarm
22 9 21 —
SPARE SPARE—unused pin
reserved for future use
— — — 10, 11, 12, 13,
23, 24, 25
Table A-9 Cisco ASR 1004 Router Specifications
Description Specification
Midplane Connects the Cisco ASR 1000 Series RP1, ASR 1000 Series ESP, Cisco ASR 1000 Series
SPA Interface (SIP), SPAs, and power supplies together in the system
Dimensions (H x W x D) Height = 7 in. (17.8 cm) (4RU rack-mount per EIA RS-310)
Width = 17.25 in. (43.815 cm) (19 inch rack-mount or optional 23 Telco rack- mount)
Depth = 22.50 in. (57.15 cm) (including card handles, cable-management brackets and
power supply handles)
Weight
• Fully loaded chassis: 50 pounds (22.6796 kg)
• Only chassis: 18 pounds (8.16 kg)
Nominal operating temperature
• 41° to 104° F
• 5° to 40° C
Nominal operating humidity 10% to 85%

Cisco ASR 1000 Series Specifications

General

Series	ASR 1000
Category	Network Router
Operating System	Cisco IOS XE
Memory	Up to 64 GB
Interfaces	10 Gigabit Ethernet
Power Supply	AC or DC options
Dimensions	Varies by model
Encryption	IPsec, SSL
Storage	Varies by model
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	5% to 95% non-condensing
MTBF	Varies by model
