2-23
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Chapter 2 Cisco ASR 1000 Series Routers Component Overview
Power Supplies for the Cisco ASR 1006 Router
AC and DC System Power Ratings
Table 2-12 lists AC and DC power supply system rating requirements for all Cisco ASR 1000 Series
Routers.
Power Supplies for the Cisco ASR 1006 Router
Note The information in this section applies to the ASR1006-PWR-DC and ASR1006-PWR-AC power
supplies. The Cisco ASR 1006 Router also supports the ASR1013/06-PWR-DC and
ASR1013/06-PWR-AC power supplies, which are described in the “Power Supplies for the Cisco ASR
1013 Router” section on page 2-44.
The Cisco ASR 1006 Router can support up to 1200 W output (AC and –48 VDC input). The 1200 W
power supply module consists of either an AC or –48 VDC input and 1200 watt output closed frame
power supply with two DC voltage outputs: 12 V and 3.3 V.
Table 2-11 Cisco ASR 1000 Series Routers AC and DC Power Supply Switches
Switch Type
Supported
Symbol Cisco ASR 1000 Series Router Power Supply
On/Off circuit I/O ASR 1006 –48 VDC
ASR 1004 –48 VDC
ASR 1002 AC
ASR 1002-X AC
Standby switch A broken
circle with
a vertical
line
through the
top of it
ASR 1006 AC
ASR 1004 AC
ASR 1002 –48 VDC
ASR 1002 +24 VDC
ASR 1013 AC and DC
ASR 1001 AC and DC
ASR 1002-X –48 VDC
ASR 1002-X +24 VDC
Table 2-12 AC and DC Power Supply System Rating Specifications for the Cisco ASR 1000 Series Routers
Description Specification
Power supply declared ratings AC = 100-240 VAC
DC = –48/ –60 VDC
+24 VDC = +21 / +36 VDC
Nominal line frequency rating 50/60 Hz for AC power supplies
