Appendix A Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002 Router, Cisco ASR 1002-F Router, and Cisco ASR 1002-X Router Specifications
Cisco ASR 1002 Router Auxiliary Port Signals and Pinouts
Note Unless stated otherwise, the specifications for the Cisco ASR 1002-X Router are the same as the Cisco
ASR 1002 Router specifications listed in this section.
Table A-19 lists the pinout of the dual RJ-45 ports for the auxiliary port signals.
Cisco ASR 1002 Router BITS Port Signals and Pinouts
Table A-20 lists the pinout of the front panel Building Integrated Timing Supply (BITS) RJ45 port.
Cisco ASR 1002-X Router BITS Port Signals and Pinouts
Table A-20 lists the pinout of the front panel Building Integrated Timing Supply (BITS) RJ45 port on
the Cisco ASR 1002-X Router.
Table A-19 Auxiliary Port Pinouts for Cisco ASR 1002 Router
Pin Signal Direction Description
1
RTS Output Request to Send
2
DTR Output Data Terminal Ready (always On)
3
TXD Output Transmit Data
4
RI — Ring Indicator
5
GND — —
6
RXD Input Receive Data
7
DSR/DCD Input Data Set Ready/Data Carrier Detect
8
CTS Input Clear to Send
Table A-20 BITS RJ-45 Interface Pinouts for Cisco ASR 1002 Router
Pin Signal Direction Description
1 RX Ring Input Receive Ring
2 RX TIP Input Receive TIP (T1/E1)
3, 4 N/C — Not used
5 TX Ring — Not used
6TX TIP — Not used
7,8 N/C — —
