Appendix A Cisco ASR 1000 Series Router Specifications
Cisco ASR 1002 Router, Cisco ASR 1002-F Router, and Cisco ASR 1002-X Router Specifications
Cisco ASR 1002 Router Mgmt Ethernet RJ-45 Port Pinouts
Note Unless stated otherwise, the specifications for the Cisco ASR 1002-X Router are the same as the Cisco
ASR 1002 Router specifications listed in this section.
The Cisco ASR 1002 Router has RJ-45 port for the 10/100/1000 Ethernet connections. The RJ-45 port
supports IEEE 802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with
10BASET, 100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45
connectors. Cisco does not supply Category 5 UTP cables; these cables are available commercially.
Table A-17 lists the RJ-45 port pinout for the front panel Management Ethernet port.
Cisco ASR 1002 Router Console Port Signals and Pinouts
Note Unless stated otherwise, the specifications for the Cisco ASR 1002-X Router are the same as the Cisco
ASR 1002 Router specifications listed in this section.
Table A-18 lists the pinout of the dual RJ-45 ports for the front panel console port.
Table A-17 Management Ethernet 10/100/1000 RJ-45 Port Pinouts for Cisco ASR 1002 Router
Pin Signal Direction Description
1 TX Data+ Output Transmit Data
2 TX Data– Output Transmit Data
3 RX Data+ Input Receive Data
4, 5 NC — —
6 RX Data– Input Receive Data
7,8 NC — —
Table A-18 Console Port Pinouts for Cisco ASR 1002 Router
Pin Signal Direction Description
1
RTS Output Request to Send (tied to CTS)
2
DTR Output Data Terminal Ready (always On)
3
TXD Output Transmit Data
4
GND — Ring Indicator
5
GND — —
6
RXD Input Receive Data
7
DSR Input unused
8
CTS Input Clear to Send (tied to RTS)
