13-3
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Chapter 13      Cisco ASR 1000 Series Routers Power Up and Initial Configuration
Powering Up the Cisco ASR 1000 Series Routers
R0        ASR1000-RP2         ok, active            22:56:46
R1        ASR1000-RP2         ok, standby           22:56:46
F0        ASR1000-ESP40       ok, active            22:56:46
F1        ASR1000-ESP40       ok, standby           22:56:46
P0        ASR1013-PWR-AC      ps, fail              22:55:56
P1        ASR1013-PWR-AC      ok                    22:55:56
P2        ASR1013-PWR-AC      ok                    22:55:56
P3        ASR1013-PWR-AC      ps, fail              22:55:56
Slot      CPLD Version        Firmware Version
--------- ------------------- ---------------------------------------
0         00200800            15.0(1r)S
1         00200800            15.0(1r)S
2         09111601            15.0(1r)S
3         00200800            15.0(1r)S
4         00200800            15.0(1r)S
5         09111601            15.0(1r)S
R0        10021901            15.0(1r)S
R1        10021901            15.0(1r)S
F0        1001270D            15.0(1r)S
F1        1001270D            15.0(1r)S
MCP_CAP_13RU#
If the LEDs indicate a power problem or the power supply state is ps, fail, then contact a customer
service representatives for assistance or additional instructions.
Powering Up the Cisco ASR 1000 Series Routers
Make certain that all card slots and compartments are closed off. Install blank faceplates on any empty
slots. Always have power supply slots filled. If you leave a power supply slot uncovered, then you risk
exposure to hazardous voltages on the power pins on the midplane.
After installing your Cisco ASR 1000 Series Routers and connecting cables, start the router.
Warning
Blank faceplates and cover panels serve three important functions: they prevent exposure to
hazardous voltages and currents inside the chassis; they contain electromagnetic interference (EMI)
that might disrupt other equipment; and they direct the flow of cooling air through the chassis. Do not
operate the system unless all cards, faceplates, front covers, and rear covers are in place.
Statement
1029
Note There is no cover on the Cisco ASR 1002 Router and the Cisco ASR 1002-X Router DC power supply
terminal block; therefore, Statement 1029 does not apply to the Cisco ASR 1002 router.
You are now ready to power on the system for the first time. Follow these steps.
Step 1 Before you power on, make sure that:
a. The AC cord is plugged into the AC power inlet.
b. All cables are connected.
c. Your computer is powered up and connected.
