Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Chapter 4 Cisco ASR 1000 Series Router SPA Interface Processors (SIPs)
SPA Interface Processor Slot Numbering
Figure 4-8 Cisco ASR 1002-X Router Subslot Numbering
1
2 4
3
333420
1 6xGE Built-in SPA in Subslot 0 3 Cisco SPA subslot 1
2 Cisco SPA subslot 2 4 Cisco SPA subslot 3
