11-15
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Chapter 11 Cisco ASR 1013 Router Overview and Installation
Rack-Mounting the Cisco ASR 1013 Router
Figure 11-6 shows the forward rack-mount brackets, callout number 2 and the rear rack-mount brackets,
callout number 4, on the Cisco ASR 1013 Router.
Figure 11-6 Forward Rack-Mount Brackets on the Cisco ASR 1013 Router
2 Forward rack-mount bracket ear and holes 4 Rear rack-mount bracket
9
2 5 6
8 7
431 2
207486
