14-48
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Chapter 14 Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing Cisco ASR 1000 Series Embedded Service Processors
%IOSXEBOOT-4-EUSB_PROVISIONING: (rp/0): Unsupported low capacity eUSB detected in 2RU
board
...
Note Even though this message is displayed, the system is permitted to proceed through it’s bring up and
should start functioning properly initially. The router should perform normally until the free resource
available in the eUSB device drops to an unacceptably low level. That low threshold is non-deterministic
and hence the invalid eUSB device should be replaced at the earliest opportunity. System behavior is
unpredictable when the eUSB resources are running low.
Removing and Replacing Cisco ASR 1000 Series Embedded
Service Processors
The following sections describe the procedures for replacing the Cisco ASR 1000 Series embedded
service processors in your system. The module also contains card handles to assist in insertion and
removal of the module and retention of the module into the chassis. The Cisco ASR 1000 Series
embedded services processors have no front panel I/O connectors.
Note See Table 1-2 for information about the embedded services processors that are supported on the various
Cisco ASR 1000 Aggregation Services Routers. On some routers, the embedded services processor is an
integral part of the router. On these routers, you cannot remove the embedded services processor. For
example, Cisco ASR1002-ESP-F is integrated on the chassis of Cisco ASR 1002-F Router.
This section contains the following topics:
• Important Notes about Cisco ASR1000-ESP Upgrades, page 14-48
• Removing a Cisco ASR1000-ESP, page 14-49
• Replacing the Cisco ASR1000-ESP, page 14-49
Note Before you begin the procedure, verify that your system meets the minimum requirements as described
in Chapter 2, “Cisco ASR 1000 Series Routers Component Overview.”
Important Notes about Cisco ASR1000-ESP Upgrades
You can upgrade from an earlier release of an embedded services processor to a later release. For
example, a router can be upgraded from Cisco ASR1000-ESP10 to Cisco ASR1000-ESP20 or from
Cisco ASR1000-ESP20 to Cisco ASR1000-ESP40.
The following sample procedure describes an upgrade from Cisco ASR1000-ESP20 to Cisco
ASR1000-ESP40 on Cisco ASR 1006 Router:
Step 1 Ensure that Cisco ASR 1006 Router has Cisco ASR1000-ESP20 in the F0 slot in the Active state.
Step 2 Insert Cisco ASR1000-ESP40 in the F1 slot. The Cisco ASR1000-ESP40 comes up as the standby.
Step 3 Reload Cisco ASR1000-ESP20. The ASR1000-ESP40 becomes active, the Cisco ASR1000-ESP20 is
disabled, and an error message is displayed.
