14-53
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
Chapter 14 Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing Cisco ASR 1000 Series Router SPAs and SPA Interface Processors
• When removing an Cisco ASR 1000 Series SPA Interface (SIP) or shared port adapter, place it on
an antistatic surface with the printed circuit board components facing upward, or in a static shielding
bag. If you are returning a shared port adapter or Cisco ASR 1000 Series SPA Interface (SIP) to the
factory, immediately place it in a static shielding bag.
Removing the Cisco ASR 1000 SPA Interface Processor
To remove a SPA Interface Processor (SIP) in the Cisco ASR 1006 Router and Cisco ASR 1004 Router,
follow these steps.
Step 1 Slip on the ESD-preventive wrist strap that was included in the accessory kit. Loosen the captive screws
on the Cisco ASR 1000 Series SPA Interface Processor.
Step 2 Using the handles on both sides of the module, with two hands gently slide the Cisco ASR 1000 Series
SPA Interface Processor out of the chassis slot.
Note Handle the Cisco ASR1000-SIP10 by the card edges only; never touch the printed circuit board
components or connector pins.
Step 3 Place the Cisco ASR1000-SIP10 on an antistatic surface with its printed circuit board components facing
upward or in a static shielding bag.
For detailed information about installing and removing SIPs and SPAs, see Cisco ASR 1000 Series
Aggregation Services Routers SIP and SPA Hardware Installation Guide.
You have completed the removal procedure for the Cisco ASR1000-SIP10.
Replacing the Cisco ASR 1000 SPA Interface Processor
To replace a SPA Interface Processor (SIP), follow these steps.
Step 1 Before inserting a SIP, make sure that the chassis is grounded.
Step 2 To insert the SIP, carefully align the edges of the SIP between the upper and lower edges of the router
slot.
Step 3 Carefully slide the SIP into the router slot until the SIP makes contact with the backplane.
Step 4 Tighten the locking thumbscrews on both sides of the SIP.
Step 5 Connect all cables to each SPA.
