Cisco ASR 1000 Series Hardware Installation Guide

B-1
Cisco ASR 1000 Series Aggregation Services Routers Hardware Installation Guide
OL-13208-11
APPENDIX
B
Cisco ASR 1000 Series Router Route Processor
and Embedded Services Processor Signals and
Pinouts
This appendix contains the following sections:
• Cisco ASR 1000-RP1 Pinout Specifications, page B-1
• Cisco ASR1000-RP2 Pinout Specifications, page B-3
• Cisco ASR1000-ESP40 Console Port Pinout Specifications, page B-4
• Cisco ASR1000-ESP100 Console Port Pinout Specifications, page B-5
• Cisco ASR1000-ESP200 Console Port Pinout Specifications, page B-5
Cisco ASR 1000-RP1 Pinout Specifications
The following tables list the pinouts for the ports on the Cisco ASR1000-RP1.
MGMT Ethernet Port Signals and Pinouts
Table B-1 lists the Management Ethernet 10/100 RJ-45 port pinouts.
Table B-1 RJ-45 Management Ethernet Port Pinouts
Pin Signal Direction Description
1 TX Data+ Output Transmit Data
2 TX Data– Output Transmit Data
3 RX Data+ Iputn Receive Data
4, 5 NC — —
6 RX Data– Input Receive Data
7,8 NC — —
