Cisco Catalyst 3750 Hardware Installation Guide

Chapter 3 Switch Installation
Installing and Removing XENPAK Modules
3-46
Catalyst 3750 Switch Hardware Installation Guide
78-15136-03
Refer to the Catalyst 3750 release notes for the list of XENPAK modules that the
Catalyst 3750G-16TD switch supports. Use only Cisco XENPAK modules on the
Catalyst 3750G-16TD switch. Each XENPAK module has an internal serial
EEPROM that is encoded with security information. This encoding provides a
way for Cisco to identify and validate that the XENPAK module meets the
requirements for the switch.
Refer to the Catalyst 3750 release notes for cable stipulations for XENPAK
module connections. For detailed instructions on installing, removing, cabling,
and troubleshooting the XENPAK module, refer to your XENPAK module
documentation.
Installing a XENPAK Module
Figure 3-40 shows a XENPAK module.
Caution We strongly recommend that you do not install or remove fiber-optic XENPAK
modules with cables attached because of the potential damage to the cables, the
cable connector, or the optical interfaces in the XENPAK module. Disconnect all
cables before removing or installing the XENPAK module.
Caution Do not remove the dust plugs from the fiber-optic XENPAK module or the rubber
caps from the fiber-optic cable until you are ready to connect the cable. The plugs
and caps protect the XENPAK module ports and cables from contamination and
ambient light.

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
