Chapter 3 Switch Installation
Preparing for Installation
Installation Guidelines
When deciding where to place the switch, be sure to observe these requirements:
• For copper Ethernet ports, including 10/100 ports and 1000BASE-T SFP
module ports, cable lengths from the switch to connected devices can be up
to 328 feet (100 meters).
• Table 3-1 lists the cable specifications for 1000BASE-SX, 1000BASE-LX,
1000BASE-ZX, and CWDM fiber-optic SFP module connections. Each port
must match the wave-length specifications on the other end of the cable, and
for reliable communications, the cable must not exceed the stipulated cable
length.
Table 3-1 Fiber-Optic SFP Module Port Cabling Specifications
SFP Module
Wavelength
(nanometers) Fiber Type
Core Size
(micron)
Modal
Bandwidth
(MHz/km) Cable Distance
1000BASE-SX 850 MMF 62.5
62.5
50
50
160
200
400
500
722 feet (220 m)
902 feet (275 m)
1640 feet (500 m)
1804 feet (550 m)
1000BASE-LX/LH 1300 MMF
1
SMF
62.5
50
50
9/10
500
400
500
—
1804 feet (550 m)
1804 feet (550 m)
1804 feet (550 m)
32,810 feet (10 km)
1000BASE-ZX 1550 SMF 9/10 — 43.4 to 62 miles (70
to 100 km)

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
