Chapter 2 Product Overview
Rear Panel Description
2-26
Catalyst 3750 Switch Hardware Installation Guide
78-15136-03
Cisco RPS Connector
Specific Cisco RPS modes support specific Catalyst 3750 switches:
• Cisco RPS 300 (model PWR300-AC-RPS-N1) supports the
Catalyst 3750-24TS, 3750G-24T, 3750G-12S, and 3750-48TS switches.
• Cisco RPS 675 (model PWR675-AC-RPS-N1=) supports the Catalyst 3750
family of switches.
Cisco RPS 300
The Cisco RPS 300 has two output levels: –48V and 12V with a total maximum
output power of 300W. Use the supplied RPS connector cable to connect the RPS
to the switch.
Note The Cisco RPS 300 does not support the Catalyst 3750G-24TS, 3750-24PS,
3750-48PS, and 3750G-16TD switches.
Warning
Attach only the Cisco RPS (model PWR300-AC-RPS-N1) to the RPS receptacle.
