Cisco Catalyst 3750 Hardware Installation Guide

CHAPTER
1-1
Catalyst 3750 Switch Hardware Installation Guide
78-15136-03
1
Using Express Setup
Express Setup is a browser-based program that you can use to set up and configure
the switch. You assign the IP information so that the switch can connect to local
routers and the Internet. The IP address is also required if you plan to further
configure the switch. This chapter provides an Express Setup procedure for a
standalone switch.
Express Setup is supported on switches running Cisco IOS Release 12.1(14)EA1
or later. When you are installing a switch, refer to the Cisco IOS release label on
the rear panel of the switch to determine the software release.
For setup instructions using the CLI-based setup program, go to Appendix C,
“Configuring the Switch with the CLI-Based Setup Program.”
Note Before connecting the switch to a power source, review the safety warnings in
Chapter 3, “Switch Installation.”
The setup procedure includes these steps:
• Taking Out What You Need, page 1-3
• Powering On the Switch, page 1-4
• Starting Express Setup, page 1-5
• Configuring the Switch, page 1-11
• Where to Go Next, page 1-14

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
