Cisco Catalyst 3750 Hardware Installation Guide

3-59
Catalyst 3750 Switch Hardware Installation Guide
78-15136-03
Chapter 3 Switch Installation
Connecting to a XENPAK Module
The LED turns amber while the STP discovers the network topology and searches
for loops. This process takes about 30 seconds, and then the port LED turns green.
If the LED is off, the target device might not be turned on, there might be a cable
problem, or there might be problem with the adapter installed in the target device.
See Chapter 4, “Troubleshooting,” for solutions to cabling problems.
Step 4 If necessary, reconfigure and restart the switch or target device.
Connecting to a XENPAK Module
Follow these steps to connect a fiber-optic cable to a XENPAK module:
Caution Do not remove the rubber plugs from the XENPAK module ports or the rubber
caps from the fiber-optic cable until you are ready to connect the cable. The plugs
and caps protect the XENPAK module ports and cables from contamination and
ambient light.
Note The 10-Gigabit Ethernet XENPAK modules are referred to as 10-Gigabit Ethernet
module ports in the switch software documentation.
Note Make sure that the XENPAK module is fully inserted into the module slot and that
the captive installation screws are fully tightened before attaching the fiber-optic
interface cable connector to the XENPAK module connector.
Step 1 Remove the rubber plugs from the XENPAK module ports and fiber-optic cable,
and store them for future use.
Step 2 Align the fiber-optic cable SC connector with the XENPAK module connector, so
that transmit (TX) on the cable meets receive (RX) on the XENPAK module
connector, and RX on the cable meets TX on the XENPAK module.
Step 3 Insert the fiber-optic cable connector into the XENPAK module ports (see
Figure 3-48).

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
