Cisco Catalyst 3750 Hardware Installation Guide

Chapter 4 Troubleshooting
Replacing a Failed Stack Member
4-10
Catalyst 3750 Switch Hardware Installation Guide
78-15136-03
Step 3 Make sure the replacement switch is powered off, and then connect the
replacement switch to the stack.
Note If you had manually set the member numbers for any members in the
stack, you need to manually assign the replacement switch the same
member number as the failed switch. To assign the member number
manually, refer to the switch software configuration guide.
Step 4 Make the same Ethernet and Gigabit Ethernet connections on the replacement
switch (as were on the failed switch).
Step 5 Power on the replacement switch.
The replacement switch will have the same configuration for all the interfaces as
the failed switch and will function the same as the failed switch.

Cisco Catalyst 3750 Specifications

General

Device Type	Switch
Switching Capacity	32 Gbps
Forwarding Rate	38.7 Mpps
Stacking Bandwidth	32 Gbps
RAM	128 MB
Jumbo Frame Support	Yes
Switch Type	Managed
Model	Catalyst 3750 Series
Uplink Interfaces	SFP
Form Factor	Rack-mountable
MAC Address Table Size	12, 000 entries
Routing Protocol	RIP, OSPF, EIGRP
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Layer 3 switching, Layer 2 switching, auto-negotiation, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, traffic shaping, MAC address filtering, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI), Cisco EnergyWise technology
Power over Ethernet (PoE)	PoE
Operating Temperature	-5 - 45 °C
Operating Humidity	10% to 85% non-condensing
