Chapter 7 Configuring Redundant Connections
Configuring Fault Tolerance
To configure the standby (B) CSM for fault tolerance, perform this task (see Figure 7-1):
Step 5
Router(config-slb-vserver)# virtual
192.158.38.30 tcp www
Creates a virtual IP address.
Step 6
Router(config-module-csm)# inservice
Enables the server.
Step 7
Router(config-module-csm)# vlan 3 server
Creates the server-side VLAN 3 and enters the SLB
VLAN mode.
Step 8
Router(config-slb-vlan-server)# ip addr
192.158.39.10 255.255.255.0
Assigns the CSM IP address on VLAN 3.
Step 9
Router(config-slb-vlan-server)# alias ip
addr 192.158.39.20 255.255.255.0
Assigns the default route for VLAN 3.
Step 10
Router(config-slb-vlan-server) vlan 9
Defines VLAN 9 as a fault-tolerant VLAN.
Step 11
Router(config-module-csm)# ft group
ft-group-number vlan 9
Creates the content switching active and standby
(A/B) group VLAN 9.
Step 12
Router(config-module-csm)# vlan
Enters the VLAN mode
1
.
Step 13
Router(vlan)# vlan 2
Configures a client-side VLAN 2
2
.
Step 14
Router(vlan)# vlan 3
Configures a server-side VLAN 3.
Step 15
Router(vlan)# vlan 9
Configures a fault-tolerant VLAN 9.
Step 16
Router(vlan)# exit
Enters the exit command to have the configuration
take affect.
1. Enter the exit command to leave a mode or submode. Enter the end command to return to the menu’s top level.
2. The no form of this command restores the defaults.
Command Purpose
Command Purpose
Step 1
Router(config-module-csm)# vlan 2 client
Creates the client-side VLAN 2 and enters the
SLB VLAN mode
1
.
Step 2
Router(config-slb-vlan-client)# ip addr
192.158.38.40 255.255.255.0
Assigns the content switching IP address on
VLAN 2.
Step 3
Router(config-slb-vlan-client)# gateway
192.158.38.20
Defines the client-side VLAN gateway.
Step 4
Router(config-module-csm)# vserver vip1
Creates a virtual server and enters the SLB
virtual server mode.
Step 5
Router(config-slb-vserver)# virtual
192.158.38.30 tcp www
Creates a virtual IP address.
Step 6
Router(config-module-csm)# inservice
Enables the server.
Step 7
Router(config-module-csm)# vlan 3 server
Creates the server-side VLAN 3 and enters the
SLB VLAN mode.
Step 8
Router(config-slb-vserver)# ip addr
192.158.39.30 255.255.255.0
Assigns the CSM IP address on VLAN 3.
Step 9
Router(config-slb-vserver)# alias
192.158.39.20 255.255.255.0
Assigns the default route for VLAN 2.
Step 10
Router(config-module-csm) vlan 9
Defines VLAN 9 as a fault-tolerant VLAN.
