DescriptionObject Name
Timestamp for SF creation (consistent with QoS MIB
model).
serviceTimeCreated
The active time of the SF in seconds.serviceTimeActive
Because the byte and packet counters are 64-bit values, it is possible for them to wrap around to zero
during a billing period. The billing application should use the sysUpTime value along with the counters
to determine whether the counters have wrapped since the last billing period. If a counter appears to
regress, and if the current sysUpTime indicates this billing cycle is the next scheduled cycle for this
particular cable modem, you can assume that the counter has wrapped during the billing cycle.
Note
These billing record objects are defined in Appendix B, IPDR Standards Submission for Cable Data
Systems Subscriber Usage Billing Records , in the DOCSIS 2.0 OSSI Specification
(SP-OSSIv2.0-IO3-021218).
Note
The following example shows a sample IPDR billing record for a downstream service flow:
<?xml version="1.0" encoding="UTF-8"?>
<IPDRDoc xmlns="http://www.ipdr.org/namespaces/ipdr"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="DOCSIS-3.1-B.0.xsd"
docId="C341A679-0000-0000-0000-000BBF54D000"
creationTime="2002-05-25T14:41:29Z"
IPDRRecorderInfo="CMTS01"
version="3.1">
</IPDR>
<IPDR xsi:type="DOCSIS-Type">
<IPDRcreationTime>2003-09-18T16:52:34Z</IPDRcreationTime>
<CMTShostname>R7519-UBR7246.cisco.com</CMTShostname>
<CMTSipAddress>1.8.8.21</CMTSipAddress>
<CMTSsysUpTime>287315 </CMTSsysUpTime>
<CMTScatvIfName>Cable8/0/0</CMTScatvIfName>
<CMTScatvIfIndex>13</CMTScatvIfIndex>
<CMTSupIfName>Ca8/0/0-upstream0</CMTSupIfName>
<CMTSupIfType>129</CMTSupIfType>
<CMTSdownIfName>Ca8/0/0-downstream</CMTSdownIfName>
<CMmacAddress>00-00-39-AB-D4-53</CMmacAddress>
<CMdocsisMode>1.0</CMdocsisMode>
<CMipAddress>3.8.21.3</CMipAddress>
<CPEipAddress></CPEipAddress>
<RecType>1</SFtype>
<serviceIdentifier>3</serviceIdentifier>
<serviceClassName></serviceClassName>
<serviceDirection>2</serviceDirection>
<serviceOctetsPassed>23457</ServiceOctetsPassed>
<servicePktsPassed>223</ServicePktsPassed>
<serviceSlaDropPkts>2</serviceSlaDropPkts>
<serviceSlaDelayPkts>0</serviceSlaDelayPkts>
<serviceTimeCreated>11000</serviceTimeCreated>
<serviceTimeActive>15890</serviceTimeActive>
</IPDR>
</IPDRDoc>
The following example shows a sample IPDR billing record for an upstream service flow:
Cisco cBR Series Converged Broadband Routers Troubleshooting and Network Management Configuration Guide
for Cisco IOS XE Fuji 16.8.x
133
Usage-Based Billing (SAMIS)
Billing Record Format
