PurposeCommand or Action
Generates RSA key pairs.crypto key generate rsa
Example:
Router(config)# crypto key generate rsa
Step 4
Returns to privileged EXEC mode.Ctrl-Z
Example:
Router(config)# Ctrl-Z
Step 5
Example:
Router#
Verifies the certificate is valid and operational on the Cisco
CMTS.
test cable read certificate
Example:
Router# test cable read certificate
Step 6
Displays the available certificates on the Cisco CMTS.show crypto ca certificate
Example:
Router# show crypto ca certificate
Step 7
Enters global configuration mode.configure terminal
Example:
Router# configure terminal
Step 8
Example:
Router(config)#
Defines the destination IP address for cable metering, to be
used with the certificate.
cable metering destination ip-addr num-1 num-2
num-3 secure
Example:
Router(config)# cable metering destination
1.7.7.7 6789 0 15 secure
Step 9
Tests cable metering in light of the supported SSL server and
metering configuration.
test cable metering
Example:
Router# test cable metering
Step 10
Cisco cBR Series Converged Broadband Routers Troubleshooting and Network Management Configuration Guide
for Cisco IOS XE Fuji 16.8.x
179
Usage-Based Billing (SAMIS)
Configuring Certified SSL Servers for Usage-Based Billing
