Cisco IE 3000 User Manual

11-5
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-01
Chapter 11 Configuring Interface Characteristics
Using Interface Configuration Mode
You can also configure a range of interfaces (see the “Configuring a Range of Interfaces” section on
page 11-6).
To configure a physical interface (port), specify the interface type, module number, and switch port number,
and enter interface configuration mode.
• Type—Fast Ethernet (fastethernet or fa) for 10/100 Mb/s Ethernet, Gigabit Ethernet (gigabitethernet
or gi) for 10/100/1000 Mb/s Ethernet ports, or small form-factor pluggable (SFP) module Gigabit
Ethernet interfaces.
• Module number—The module number on the switch. The module number (1 to 3) depends on how
the module is connected to the switch or to other modules.
– The module number for the IE-3000-4TC and IE-3000-8TC switches is 1.
– The module number for a module that is directly connected to the switch is 2.
– The module number for a module that is connected to another module is 3.
• Port number—The physical interface number on the switch. The port numbers for the IE-3000-4TC
switch model are 1–4 for the Fast Ethernet ports and 1–2 for the Gigabit Ethernet ports. The port
numbers for the IE-3000-8TC switch model are 1–8 for the Fast Ethernet ports and 1–2 for the
Gigabit Ethernet ports.
Table 11-1 shows the switch and module combinations and the interface
numbers.
You can identify physical interfaces by looking at the switch. You can also use the show privileged
EXEC commands to display information about a specific interface or all the interfaces. The remainder
of this chapter primarily provides physical interface configuration procedures.
Ta b l e 11-1 Switch Interface Numbers
Switch Model
Module
Number
Interface Numbering Scheme
IE-3000-4TC switch 1 Fast Ethernet1/1, Fast Ethernet1/2, Fast
Ethernet1/3, Fast Ethernet1/4, Gigabit Ethernet1/1,
and Gigabit Ethernet1/2
IE-3000-8TC switch 1 Fast Ethernet1/1, Fast Ethernet1/2, Fast
Ethernet1/3, Fast Ethernet1/4, Fast Ethernet1/5,
Fast Ethernet1/6, Fast Ethernet1/7, Fast
Ethernet1/8, Gigabit Ethernet1/1, and Gigabit
Ethernet1/2
IEM-3000-8TM expansion module
(connected to the switch)
2 Fast Ethernet2/1, Fast Ethernet2/2, Fast
Ethernet2/3, Fast Ethernet2/4, Fast Ethernet2/5,
Fast Ethernet2/6, Fast Ethernet2/7, and Fast
Ethernet2/8
IEM-3000-8TM expansion module
(connected to another module)
3 Fast Ethernet3/1, Fast Ethernet3/2, Fast
Ethernet3/3, Fast Ethernet3/4, Fast Ethernet3/5,
Fast Ethernet3/6, Fast Ethernet3/7, and Fast
Ethernet3/8

Cisco IE 3000 Specifications

General

Operating Temperature	-40 to 75°C (-40 to 167°F)
DRAM	128 MB
Flash Memory	32 MB
Uplink Ports	2 x 10/100/1000Base-T or SFP
MAC Address Table Size	8000
Mounting	DIN rail, Wall
