30-20
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-01
Chapter 30 Configuring Network Security with ACLs
Creating Named MAC Extended ACLs
For more information about the supported non-IP protocols in the mac access-list extended command,
see the command reference for this release.
Note Though visible in the command-line help strings, appletalk is not supported as a matching condition for
the deny and permit MAC access-list configuration mode commands.
Beginning in privileged EXEC mode, follow these steps to create a named MAC extended ACL:
Use the no mac access-list extended name global configuration command to delete the entire ACL. You
can also delete individual ACEs from named MAC extended ACLs.
This example shows how to create and display an access list named mac1, denying only EtherType
DECnet Phase IV traffic, but permitting all other types of traffic.
Switch(config)# mac access-list extended mac1
Switch(config-ext-macl)# deny any any decnet-iv
Switch(config-ext-macl)# permit any any
Switch(config-ext-macl)# end
Switch # show access-lists
Extended MAC access list mac1
10 deny any any decnet-iv
20 permit any any
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
mac access-list extended name Define an extended MAC access list using a name.
Step 3
{deny | permit} {any | host source MAC
address | source MAC address mask} {any |
host destination MAC address | destination
MAC address mask} [type mask | lsap lsap mask
| aarp | amber | dec-spanning | decnet-iv |
diagnostic | dsm | etype-6000 | etype-8042 | lat
| lavc-sca | mop-console | mop-dump | msdos |
mumps | netbios | vines-echo |vines-ip |
xns-idp | 0-65535] [cos cos]
In extended MAC access-list configuration mode, specify to
permit or deny any source MAC address, a source MAC address
with a mask, or a specific host source MAC address and any
destination MAC address, destination MAC address with a mask,
or a specific destination MAC address.
(Optional) You can also enter these options:
• type mask—An arbitrary EtherType number of a packet with
Ethernet II or SNAP encapsulation in decimal, hexadecimal,
or octal with optional mask of don’t care bits applied to the
EtherType before testing for a match.
• lsap lsap mask—An LSAP number of a packet with
IEEE
802.2 encapsulation in decimal, hexadecimal, or octal
with optional mask of don’t care bits.
• aarp | amber | dec-spanning | decnet-iv | diagnostic | dsm |
etype-6000 | etype-8042 | lat | lavc-sca | mop-console |
mop-dump | msdos | mumps | netbios | vines-echo |vines-ip
| xns-idp—A non-IP protocol.
• cos cos—An IEEE 802.1Q cost of service number from 0 to 7
used to set priority.
Step 4
end Return to privileged EXEC mode.
Step 5
show access-lists [number | name] Show the access list configuration.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
