32-22
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-01
Chapter 32 Configuring QoS
Configuring Auto-QoS
If you entered the auto qos voip trust command, the switch
automatically sets the ingress classification to trust the CoS
value received in the packet on a nonrouted port by using the
mls qos trust cos command.
Switch(config-if)# mls qos trust cos
Switch(config-if)# mls qos trust dscp
If you entered the auto qos voip cisco-phone command, the
switch automatically enables the trusted boundary feature,
which uses the CDP to detect the presence or absence of a
Cisco IP Phone.
Switch(config-if)# mls qos trust device cisco-phone
If you entered the auto qos voip cisco-softphone command,
the switch automatically creates class maps and policy maps.
Switch(config)# mls qos map policed-dscp 24 26 46 to
0
Switch(config)# class-map match-all
AutoQoS-VoIP-RTP-Trust
Switch(config-cmap)# match ip dscp ef
Switch(config)# class-map match-all
AutoQoS-VoIP-Control-Trust
Switch(config-cmap)# match ip dscp cs3 af31
Switch(config)# policy-map AutoQoS-Police-SoftPhone
Switch(config-pmap)# class AutoQoS-VoIP-RTP-Trust
Switch(config-pmap-c)# set dscp ef
Switch(config-pmap-c)# police 320000 8000
exceed-action policed-dscp-transmit
Switch(config-pmap)# class
AutoQoS-VoIP-Control-Trust
Switch(config-pmap-c)# set dscp cs3
Switch(config-pmap-c)# police 32000 8000
exceed-action policed-dscp-transmit
After creating the class maps and policy maps, the switch
automatically applies the policy map called
AutoQoS-Police-SoftPhone to an ingress interface on which
auto-QoS with the Cisco SoftPhone feature is enabled.
Switch(config-if)# service-policy input
AutoQoS-Police-SoftPhone
If you entered the auto qos voip cisco-phone command, the
switch automatically creates class maps and policy maps.
witch(config)# mls qos map policed-dscp 24 26 46 to
0
Switch(config)# class-map match-all
AutoQoS-VoIP-RTP-Trust
Switch(config-cmap)# match ip dscp ef
Switch(config)# class-map match-all
AutoQoS-VoIP-Control-Trust
Switch(config-cmap)# match ip dscp cs3 af31
Switch(config)# policy-map AutoQoS-Police-CiscoPhone
Switch(config-pmap)# class AutoQoS-VoIP-RTP-Trust
Switch(config-pmap-c)# set dscp ef
Switch(config-pmap-c)# police 320000 8000
exceed-action policed-dscp-transmit
Switch(config-pmap)# class
AutoQoS-VoIP-Control-Trust
Switch(config-pmap-c)# set dscp cs3
Switch(config-pmap-c)# police 32000 8000
exceed-action policed-dscp-transmit
After creating the class maps and policy maps, the switch
automatically applies the policy map named
AutoQoS-Police-CiscoPhone to an ingress interface on which
auto-QoS with the Cisco Phone feature is enabled.
Switch(config-if)# service-policy input
AutoQoS-Police-CiscoPhone
Table 32-5 Generated Auto-QoS Configuration (continued)
Description Automatically Generated Command

Cisco IE 3000 Specifications

General

Operating Temperature	-40 to 75°C (-40 to 167°F)
DRAM	128 MB
Flash Memory	32 MB
Uplink Ports	2 x 10/100/1000Base-T or SFP
MAC Address Table Size	8000
Mounting	DIN rail, Wall
