Cisco IE 3000 User Manual

33-11
Cisco IE 3000 Switch Software Configuration Guide
OL-13018-01
Chapter 33 Configuring EtherChannels and Link-State Tracking
Configuring EtherChannels
To remove a port from the EtherChannel group, use the no channel-group interface configuration
command.
Step 3
switchport mode {access | trunk}
switchport access vlan vlan-id
Assign all ports as static-access ports in the same VLAN, or
configure them as trunks.
If you configure the port as a static-access port, assign it to only
one VLAN. The range is 1 to 4094.
Step 4
channel-group channel-group-number mode
{auto [non-silent] | desirable [non-silent] | on} |
{active | passive}
Assign the port to a channel group, and specify the PAgP or the
LACP mode.
For channel-group-number, the range is 1 to 6.
For mode, select one of these keywords:
• auto—Enables PAgP only if a PAgP device is detected. It
places the port into a passive negotiating state, in which the
port responds to PAgP packets it receives but does not start
PAgP packet negotiation.
• desirable—Unconditionally enables PAgP. It places the port
into an active negotiating state, in which the port starts
negotiations with other ports by sending PAgP packets.
• on—Forces the port to channel without PAgP or LACP. In
the on mode, an EtherChannel exists only when a port group
in the on mode is connected to another port group in the on
mode.
• non-silent—(Optional) If your switch is connected to a
partner that is PAgP-capable, configure the switch port for
nonsilent operation when the port is in the auto or desirable
mode. If you do not specify non-silent, silent is assumed.
The silent setting is for connections to file servers or packet
analyzers. This setting allows PAgP to operate, to attach the
port to a channel group, and to use the port for transmission.
• active—Enables LACP only if a LACP device is detected. It
places the port into an active negotiating state in which the
port starts negotiations with other ports by sending LACP
packets.
• passive—Enables LACP on the port and places it into a
passive negotiating state in which the port responds to LACP
packets that it receives, but does not start LACP packet
negotiation.
For information on compatible modes for the switch and its
partner, see the
“PAgP Modes” section on page 33-4 and the
“LACP Modes” section on page 33-5.
Step 5
end Return to privileged EXEC mode.
Step 6
show running-config Verify your entries.
Step 7
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose

Cisco IE 3000 Specifications

General

Operating Temperature	-40 to 75°C (-40 to 167°F)
DRAM	128 MB
Flash Memory	32 MB
Uplink Ports	2 x 10/100/1000Base-T or SFP
MAC Address Table Size	8000
Mounting	DIN rail, Wall
