Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
OL-16597-01
Chapter 1 Configuring ACLs
Configuring VACLs
To apply a VACL to a VLAN, perform this task:
Verifying VACL Configuration
To display VACL configuration information, perform one of the following tasks:
Displaying and Clearing VACL Statistics
To display or clear VACL statistics, perform one of the following tasks:
This example shows how to configure a VACL to forward traffic permitted by an IP ACL named
acl-ip-01and how to apply the VACL to VLANs 50 through 82:
configure terminal
vlan access-map acl-ip-map
match ip address acl-ip-01
Command Purpose
Step 1
switch# configure terminal
Enters global configuration mode.
Step 2
switch(config)# [no] vlan filter map-name
vlan-list list
Applies the VACL to the VLANs by the list that you
specified. The no option unapplies the VACL.
The vlan-list command can specify a list of up to 32
vlans, but multiple vlan-list commands can be
configured to cover more than 32 vlans.
Step 3
switch(config)# show running-config
(Optional) Displays ACL configuration.
Step 4
switch(config)# copy running-config
startup-config
(Optional) Copies the running configuration to the
startup configuration.
Command Purpose
show running-config aclmgr Displays ACL configuration, including
VACL-related configuration.
show vlan filter Displays information about VACLs that are
applied to a VLAN.
show vlan access-map Displays information about VLAN access maps.
Command Purpose
show vlan access-list Displays VACL configuration. If the VLAN
access-map includes the statistics command, then
the show vlan access-list command output
includes the number of packets that have matched
each rule.
clear vlan access-list counters Clears statistics for all VACLs or for a specific
VAC L .
