Managing the System
Applications
Cisco Small Business NSS300 Series Smart Storage Administration Guide 200
3
To create a new RADIUS client:
STEP 1 Choose Applications > RADIUS Server > RADIUS Clients from the Navigation
menu. The RADIUS Clients window opens.
STEP 2 Click Create a New Client to create a new RADIUS client, such as a router, switch,
or WAP. Enter the following parameters:
• Name—Name of the new RADIUS client.
• IP Address—IP address for the new RADIUS client.
• Prefix Length—Prefix length for the new RADIUS client. The number of bits
in an IP address that specify its network number. IP addresses have two
subcomponents; a network part and a host part. For example, a value of 24
entered into the prefix length will have a single network and 254 hosts
available in those IP addresses.
• Secret Key—Secret key for the new RADIUS client. The secret key must be
at least six characters. Use this same secret key and input at the router,
switch, or WAP administration configuration parameters for their own
RADIUS options.
STEP 3 Click Apply to save the new client settings.
RADIUS Users
From the Applications > RADIUS Server > RADIUS Users window, you can
configure the RADIUS user settings. RADIUS users are the specific end points
such as PCs and devices actually attempting to connect to and gain access to
network resources.
