Using the LCD Display
Viewing System Information Using the LCD Display
Cisco Small Business NSS300 Series Smart Storage Administration Guide 257
7
• LAN SEC. DNS—Second DNS server.
In Network Settings, press the Enter button to enter the Network Settings. Press
the Select button to move forward through the options.
• Network Settings:
- Network Settings – DHCP—Specifies whether this interface uses
Dynamic Host Configuration Protocol (DHCP).
- Network Settings – Static IP—If a static IP address is configured,
shows static IP address, subnet mask, gateway, and DNS of LAN 1 and
LAN 2.
- Network Settings – BACK—Move back in the menu options.
• Back to Main Menu—Return to the Main Menu.
Physical Disk
In Physical disk, you can view the following options:
•Disk Info
• Back to Main Menu
To view the physical disk:
STEP 1 From the Main Menu, press the Select button until the Physical disk option is
displayed.
STEP 2 Press the Enter button. The Disk Info shows the temperature and the capacity of
the first disk.
STEP 3 Press the Select button to view each disk.
STEP 4 When Back to Main Menu is displayed, press the Enter button to return to the Main
Menu.
D i s k : 1 T e m p : 5 0
°
C
S i z e : 2 3 2 G B
