Using the LCD Display
Viewing System Information Using the LCD Display
Cisco Small Business NSS300 Series Smart Storage Administration Guide 258
7
Volume
The Volume option shows the disk configuration of the NAS.
To v i e w t h e v o l u m e :
STEP 1 From the Main Menu, press the Select button until the Volume option is displayed.
STEP 2 Press the Enter button. The first line shows the RAID configuration and storage
capacity. The second line shows the member drive number of the configuration.
STEP 3 If there is more than one volume, press the Select button to view the information.
STEP 4 When Back to Main Menu is displayed, press the Enter button to return to the Main
Menu.
The following table shows the description of the LCD messages for RAID 5
configuration.
R A I D 5 7 5 0 G B
D r i v e 1 2 3 4
LCD Display Drive Configuration
RAID 5+S RAID 5 + spare
RAID 5 (D) RAID 5 degraded mode
RAID 5 (B) RAID 5 rebuilding
RAID 5 (S) RAID 5 re-synchronizing
RAID 5 (U) RAID 5 is unmounted
RAID 5 (X) RAID 5 non-activated
