Cisco SF200-24 User Manual

Smartports
Built-in Smartport Macros
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 122
9
desktop
[desktop]
#interface configuration, for increased network security and reliability when connecting a desktop
device, such as a PC, to a switch port.
#macro description Desktop
#macro keywords $native_vlan $max_hosts
#
#macro key description: $native_vlan: The untag VLAN which will be configured on the port
# $max_hosts: The maximum number of allowed devices on the port
#Default Values are
#$native_vlan = Default VLAN
#$max_hosts = 10
#
#the port type cannot be detected automatically
#
#the default mode is trunk
smartport switchport trunk native vlan $native_vlan
#
port security max $max_hosts
port security mode max-addresses
port security discard trap 60
#
smartport storm-control broadcast level 10
smartport storm-control include-multicast
smartport storm-control broadcast enable
#
spanning-tree portfast
#
@

Cisco SF200-24 Specifications

General

Model	SF200-24
Switching Capacity	8.8 Gbps
Layer	Layer 2
Form Factor	Rack-mountable
Power Supply	Internal
MAC Address Table Size	8000 entries
Switch Type	Managed
Power over Ethernet (PoE)	No
Stackable	No
Jumbo Frame Support	9216 bytes
VLAN Support	Yes
Quality of Service (QoS)	4 hardware queues
Ports	24
