VLAN Management
Voice VLAN
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 175
12
• The voice flow is accepted if the MAC address can be learned by the
Forwarding Database (FDB). (If there is no free space in FDB, no action
occurs).
Voice VLAN Workflows
The switch default configuration on Auto Voice VLAN, Auto Smartports, CDP, and
LLDP cover most common voice deployment scenarios. This section describes
how to deploy voice VLAN when the default configuration does not apply.
Workflow1: To configure Auto Voice VLAN:
STEP 1 Open the
VLAN Management >
Voice VLAN > Properties page.
STEP 2 Select the Voice VLAN ID. It cannot be set to VLAN ID 1 (this step is not required for
dynamic Voice VLAN).
STEP 3 Set Dynamic Voice VLAN to Enable Auto Voice VLAN.
STEP 4 Select the Auto Voice VLAN Activation method.
NOTE If the device is currently in Telephony OUI mode, you must disable it
before you can configure Auto Voice Vlan
STEP 5 Click Apply.
STEP 6 Configure Smartports as described in the Common Smartport Tasks section.
STEP 7 Configure LLDP/CDP as described in the Configuring LLDP and Configuring
CDP sections, respectively.
STEP 8 Enable the Smartport feature on the relevant ports using the Smartport >
Interface Settings page.
Workflow2: To configure the Telephony OUI Method
STEP 1 Open the
VLAN Management >
Voice VLAN > Properties page. Set Dynamic
Voice VLAN to Enable Telephony OUI.
NOTE If the device is currently in Auto Voice VLAN mode, you must disable
it before you can enable Telephony OUI.
STEP 2 Configure Telephony OUI in the Te le ph o ny OU I page.
STEP 3 Configure Telephony OUI VLAN membership for ports in the Tel ep hony OUI
Interface page.
