Configuring Discovery
Configuring LLDP
Cisco Small Business 200 1.1 Series Smart Switch Administration Guide 75
7
- Size (Bytes) —Total LLDP MED extended power via MDI packets byte
size.
-
Status —If the LLDP MED extended power via MDI packets were sent, or
if they were overloaded.
• 802.3 TLVs
-
Size (Bytes) —Total LLDP MED 802.3 TLVs packets byte size.
-
Status —If the LLDP MED 802.3 TLVs packets were sent, or if they were
overloaded.
• LLDP Optional TLVs
-
Size (Bytes) —Total LLDP MED optional TLVs packets byte size.
-
Status —If the LLDP MED optional TLVs packets were sent, or if they were
overloaded.
• LLDP MED Inventory
-
Size (Bytes) —Total LLDP MED inventory TLVs packets byte size.
-
Status —If the LLDP MED inventory packets were sent, or if they were
overloaded.
• Total (By tes)—Total number of bytes of LLDP information in each packet
• Left to Send (Bytes)—Total number of available bytes left for additional
LLDP information in each packet.
