Cisco WAP200 Administration Guide

Installing the Access Point
Connecting the Equipment
Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster 12
4
Connecting the Equipment
You can connect the WAP200 access point to your network in one of the following
ways:
• Using a PoE switch
• Using a standard switch
Using a PoE Switch to Connect the WAP200 to the Network
To connect the WAP200 access point to your network using a PoE switch, simply
connect the Ethernet port of the access point to an Ethernet port on the PoE
switch.
The LEDs on the front panel light up when the WAP200 access point powers on.

Cisco WAP200 Specifications

General

Networking standards	IEEE 802.3af, IEEE 802.11b, IEEE 802.11g
Supports ISDN connection	No
DHCP client	Yes
DHCP server	-
Security algorithms	WEP, WPA, WPA2
Dimensions (WxDxH)	170 x 195 x 205 mm
Storage temperature (T-T)	20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Wi-Fi standards	802.11g, 802.11b
Top Wi-Fi standard	802.11g
Ethernet LAN (RJ-45) ports	1
Product color	Gray

Weight and Dimensions

Weight	400 g
