Cisco WAP200 Administration Guide

Installing the Access Point
Connecting the Equipment
Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster 13
4
Using a Standard Switch to Connect the WAP200 to the
Network
To connect the WAP200 access point to your network using a standard switch,
follow these steps.
STEP 1 Use the supplied Ethernet cable to connect the Ethernet port of the access point to
an Ethernet port on the switch.
STEP 2 Connect the included power adapter to the Power port of the WAP200 access
point.
STEP 3 Plug the power adapter into an electrical outlet.
The LEDs on the front panel light up when the WAP200 access point powers on.

Cisco WAP200 Specifications

General

Networking standards	IEEE 802.3af, IEEE 802.11b, IEEE 802.11g
Supports ISDN connection	No
DHCP client	Yes
DHCP server	-
Security algorithms	WEP, WPA, WPA2
Dimensions (WxDxH)	170 x 195 x 205 mm
Storage temperature (T-T)	20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Wi-Fi standards	802.11g, 802.11b
Top Wi-Fi standard	802.11g
Ethernet LAN (RJ-45) ports	1
Product color	Gray

Weight and Dimensions

Weight	400 g
