Cisco WAP200 Administration Guide

Configuring the WAP200 Access Point
Setting Up Your Access Point
Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster 22
6
Configuring Network Setup Settings
To configure the network setup settings of the access point, follow these steps:
STEP 1 Click Setup > Basic Setup.
STEP 2 From the IP Settings drop-down menu, select one of the following options:
• Static IP Address—Select this option to assign a static or fixed IP address
to the access point.
• Automatic Configuration - DHCP—If you have a DHCP server enabled on
the LAN and want it to assign an IP address to the access point, select this
option.
STEP 3 If you selected Static IP Address, enter the following information in the Network
Setup section:
• Local IP Address—Enter the IP address of the access point. Make sure the
address is not used by other devices on the network. The default is
192.168.1.245.
• Subnet Mask—Enter the subnet mask of your network. The default is
255.255.255.0.
• Default Gateway—Enter the default gateway address, typically the IP
address of your router.
• Primary DNS—Enter the IP address of the Domain Name System (DNS)
server. This address is typically provided by your Internet Service Provider
(ISP).
• Secondary DNS—Optional. Enter a second DNS server.
STEP 4 Click Save.

Cisco WAP200 Specifications

General

Networking standards	IEEE 802.3af, IEEE 802.11b, IEEE 802.11g
Supports ISDN connection	No
DHCP client	Yes
DHCP server	-
Security algorithms	WEP, WPA, WPA2
Dimensions (WxDxH)	170 x 195 x 205 mm
Storage temperature (T-T)	20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Wi-Fi standards	802.11g, 802.11b
Top Wi-Fi standard	802.11g
Ethernet LAN (RJ-45) ports	1
Product color	Gray

Weight and Dimensions

Weight	400 g
