Cisco WAP200 Administration Guide

Configuring the WAP200 Access Point
Configuring Wireless Settings
Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster 38
6
STEP 5 Provide the following information:
• RADIUS Server IP Address—Enter the RADIUS server’s IP address.
• RADIUS Server Port—Enter the port number used by the RADIUS server.
The default is 1812.
• Encryption—Mixed Mode automatically chooses TKIP or AES for data
encryption.
• Shared Secret—Enter the shared secret key used by the access point and
RADIUS server.
• Key Renewal Timeout—Enter a key renewal timeout period, which instructs
the access point how often it should change the encryption keys. The default
is 3600 seconds.
STEP 6 Click Save.

Cisco WAP200 Specifications

General

Networking standards	IEEE 802.3af, IEEE 802.11b, IEEE 802.11g
Supports ISDN connection	No
DHCP client	Yes
DHCP server	-
Security algorithms	WEP, WPA, WPA2
Dimensions (WxDxH)	170 x 195 x 205 mm
Storage temperature (T-T)	20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Wi-Fi standards	802.11g, 802.11b
Top Wi-Fi standard	802.11g
Ethernet LAN (RJ-45) ports	1
Product color	Gray

Weight and Dimensions

Weight	400 g
