Cisco WAP200 Administration Guide

Configuring the WAP200 Access Point
Configuring Wireless Settings
Cisco WAP200 Wireless-G Access Point with Power Over Ethernet and Rangebooster 42
6
STEP 5 Provide the following information:
• Authentication Type—Choose the 802.11 authentication type as either
Open System or Shared Key. The default is Open System.
• Default Transmit Key—Select the key to be used for data encryption.
• Encryption—Select a level of WEP encryption, 64 bits (10 hex digits) or 128
bits (26 hex digits).
• Passphrase—If you want to generate WEP keys using a passphrase, then
enter the passphrase in the field provided and click Generate. The auto-
generated keys are not as strong as manual WEP keys.
• Key 1–4—If you want to manually enter WEP keys, then complete the fields
provided. Each WEP key can consist of the letters “A” through “F” and the
numbers “0” through “9.” A WEP key should be 10 characters long for 64-bit
encryption or 26 characters long for 128-bit encryption.
STEP 6 Click Save.

Cisco WAP200 Specifications

General

Networking standards	IEEE 802.3af, IEEE 802.11b, IEEE 802.11g
Supports ISDN connection	No
DHCP client	Yes
DHCP server	-
Security algorithms	WEP, WPA, WPA2
Dimensions (WxDxH)	170 x 195 x 205 mm
Storage temperature (T-T)	20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %
Wi-Fi standards	802.11g, 802.11b
Top Wi-Fi standard	802.11g
Ethernet LAN (RJ-45) ports	1
Product color	Gray

Weight and Dimensions

Weight	400 g
