Citrix ADC MPX
Key Function
. Processes the information, or terminates the
configuration, if none of the values are
changed. This key is also known as the ENTER
key.
To perform the initial configuration by using the LCD keypad press the “<” key.
You are prompted to enter the subnet mask, Citrix ADC IP address (NSIP), and gateway in that order
respectively. The subnet mask is associated with both the NSIP and default gateway IP address. The
NSIP is the IPv4 address of the Citrix ADC appliance. The default gateway is the IPv4 address for the
router, which will handle external IP traic that the Citrix ADC cannot otherwise route. The NSIP and
the default gateway should be on the same subnet.
If you enter a valid value for the subnet mask, such as 255.255.255.224, you are prompted to enter
the IP address. Similarly, if you enter a valid value for the IP address, you are prompted to enter the
gateway address. If the value you entered is invalid, the following error message appears for three
seconds, where xxx.xxx.xxx.xxx is the IP address you entered, followed by a request to re-enter
the value.
1 Invalid addr!
2 xxx.xxx.xxx.xxx
If you press the ENTER (.) key without changing any of the digits, the soware interprets this as a user
exit request. The following message will be displayed for three seconds.
1 Exiting menu...
2 xxx.xxx.xxx.xxx
If all the values entered are valid, when you press the ENTER key, the following message appears.
1 Values accepted,
2 Rebooting...
The subnet mask, NSIP, and gateway values are saved in the configuration file.
Note: For information about deploying a high availability (HA) pair, see https://docs.citrix.com/en-
us/netscaler/12-1/system/high-availability-introduction.html.
© 1999-2019 Citrix Systems, Inc. All rights reserved. 127
