Citrix ADC MPX Series User Manual

Citrix ADC MPX
Command:
1 sh raid
Output:
1 RAID1 status: READY
2 Drive:
3 1 ONLINE
4 2 ONLINE
5 Done
If both SSDs show ONLINE and RAID status is READY, no action is required.
In the following table, the values in the first column show the drive number on the back panel of the
appliance. The drive number in the other columns refers to the number that should be used in the
command or as it appears in the output of the CLI and shell.
Chassis CLI command Shell command Shell command Shell command
Slot in chassis sh raid atacontrol status
ar0
atacontrol
detach /
atacontrol
attach
atacontrol
addspare ar0
SSD 1 drive 1 drive 0 ata2 ad4
SSD 2 drive 2 drive 1 ata3 ad6
The following output indicates SSD 2 has failed and should be replaced.
Command:
1 sh raid
Output:
1 RAID1 status: DEGRADED
2 Drive:
3 1 ONLINE
4 2 MISSING
5 Done
Sometimes, the failed drive/SSD may not be reported.
Command:
© 1999-2019 Citrix Systems, Inc. All rights reserved. 96
