Table 6: PDE4663 - Ethernet RJ45
Description
Pin
Number
Data Transmit (TD+) 1
Data Transmit (TD-) 2
Data receive RD+) 3
-4
-5
Data Receive (RD-) 6
-7
-8
Table 7: PDE4663 - Serial 1 and 2
Description
Pin
Number
-1
Data Receive (Rx) 2
Data Transmit (Tx) 3
-4
Screen 5
-6
-7
-8
-9
