Technical Manual Issue 2.1 4000 Digital Series II

Page 26 STA0381

2.2.9.3 PD4225R/PD4225 Rear View

Figure 20 - PD4225R/PD4225 Rear view

1 Earth Connection 5 Matrix Comms Connector (BNC) (Optional)

2 DC Power Connector (DIN) 6 Extension Panel Connector

3 Control I/O (Optional) 7 Matrix Comms Connector (RJ45)

4 Audio I/O (Optional)

2 3 4 5 6 71
