4000 Digital Series II Issue 2.1 Technical Manual

STA0381 Page 71

circuit and a common Output RAM. A block diagram is shown below. Note that the block diagram only

illustrates one router.

A sub-fitted version of this card is used in the smaller 4420 matrices. This card has one quarter of the

routing capacity of the fully fitted card.

Figure 66 - PDE 3601A - Block Diagram

For a description of the functioning of the LEDs on the card refer to the

4000 Installation Guide.
