Technical Manual Issue 2.1 4000 Digital Series II
Page 22 STA0381
2.2.8.4 PD4224R/PD4224 Rear View
Figure 17 - PD4224R/PD4224 Rear View
2.2.8.5 PD4224R/PD4224 Components
1 Earth Connection 5 Matrix Comms Connector (BNC) (Optional)
2 DC Power Connector (DIN) 6 Extension Panel Connector
3 Control I/O (Optional) 7 Matrix Comms Connector (RJ45)
4 Audio I/O (Optional)
2 3 4 5 6 7 1
4224
CONTROL PANEL
PDE 4535
PROCESSOR CARD
PDE 4551
SWITCH CARD
PDE 4537
AUDIO/CONTROL I/O
OPTIONS CARD
PDE 4536
COAX/FIBRE OPTIC
OPTIONS CARD
