Clear-Com 4000 II Series User Manual

Technical Manual Issue 2.1 4000 Digital Series II
Page 60 STA0381
This card contains the 12 LCD keys for the PD4211 panel and In its fully fitted form
(/LVL) it also contains the encoders and associated LEDs for the PD4212 panel.
3.4 PDE 4532 2U LCD Key Card
Figure 52 - PDE4532 LCD Key Card
This card contains the 12 LCD keys for the PD4211 panel and In its fully fitted form
(/LVL) it also contains the encoders and associated LEDs for the PD4212 panel.
3.5 PDE 4533 Key/Pot. Card
Figure 53 - PDE4533 Key/Pot Card
This card contains the main and auxiliary level control encoders and the four function keys with their
associated LEDS for the PD4211/4212/4221/4222 panels.
3.6 PDE 4534 RJ45 Connector Card
Figure 54 - PDE4534 RJ45 Connector Card
This card contains just a pcb mounted RJ45 connector for serial interconnection of the PD4294 desktop
panel.
