2.2.10.3 PD4226 Rear View
2.2.10.4 PD4226R/PD4226 Components
Mechanical construction and wiring are shown in the associated drawings.
1 Earth Connection 5 Matrix Comms Connector (BNC) (Optional)
2 DC Power Connector (DIN) 6 Extension Panel Connector
3 Control I/O (Optional) 7 Matrix Comms Connector (RJ45)
4 Audio I/O (Optional)
2 3 4 5 6 7 1
4226
CONTROL PANEL
PDE 4535
PROCESSOR CARD
PDE 4552
SWITCH CARD
PDE 4537
AUDIO/CONTROL I/O
OPTIONS CARD
PDE 4536
COAX/FIBRE OPTIC
OPTIONS CARD
