Coastcom D/I Mux III System User Manual

Chapter 4. Configuration and Operation
102
CCU System Access Screen - Figure 4-2
AC (Access CCU - D/I Mux III User Submenu) - Figure 4-6
⎪
├──Shelf Configuration
⎪ DC (Display Shelf Configuration) - Figure 4-11
⎪ SC (Set Shelf Configuration) - Figure 4-44
├──System Parameters
⎪ DV (Display Smart AC PS if used) - Figure 4-21
⎪ SR (Set Communications Rate) - Figure 4-61
⎪ SP (Set System Parameters) - Figure 4-60
⎪ DP (Display System Parameters) - Figure 4-18
├──Line Cards
⎪ DL (Display Table) - Figure 4-14
⎪ CL (Copy Line Card Configuration) - Figure 4-8
⎪ DD (Display Line Card Configuration) - Figure 4-12
⎪ SL (Set Line Card Configuration) - Figure 4-53
├──Map Matrix
│ DM (Display Map Matrix) - Figure 4-15
│ SM (Set/Edit Map Matrix) - Figure 4-54
│ CM (Copy Map Matrix) - Figure 4-9
├──Map Table
│ DT (Display Map Table) - Figure 4-20
│ ST (Set/Edit Map Table) - Figure 4-64
│ DN (Display Working Map) - Figure 4-17
│ SN (Set Working Map) - Figure 4-58
├──Clock Source
│ DS (Display Clock Source) - Figure 4-19
│ SS (Set Clock Source) - Figure 4-62
├──Performance
│ PM (FDL Monitor) - Figure 4-37
│ DH (Display Alarm History) - Figure 4-13
│ SB (Set Error Rate) - Figure 4-41
│ ZH (Clear Alarm History) - Figure 4-71
├──Passwords
│ LO (Logout─Returns to MCU Main Menu) - Figure 4-24
│ DW (Display Passwords) - Figure 4-22
│ SW (Set/Install Passwords) - Figure 4-65
│ EW (Erase Passwords) - Figure 4-23
├──Alarms
│ DA (Display Alarms) - Figure 4-10
│ ZA (Clear Counts) - Figure 4-70
│ SO (Set Communications Reports) - Figure 4-59
└──Diagnostics
OL (Line Card) - Figure 4-34
OD (T1-CSU) - Figure 4-33
MCU Main Menu - Figures 4-3, 4-4, 4-5
│
├──Local Parameters
│ VR (View Revision Levels) - Figure 4-69
│ MT (Modify Keyboard Time-Out) - Figure 4-32
├──Network Parameters
│ VN (View Network Parameters) - Figure 4-67
│ MG (Modify Default Gateway) - Figure 4-26
│ MI (Modify IP Address) - Figure 4-27
│ MS (Modify Subnet Mask) - Figure 4-31
│ ML (Modify SLIP Parameters) Figure 4-28
├───Code Download
│ MC (Download CCU Program) - Figure 4-25
├───Passwords
│ VP (View Passwords) - Figure 4-68
│ MP (Modify/Install Passwords) - Figure 4-30
│ RP (Remove Passwords) - Figure 4-40
│ Q (Quit/Disconnect) - Figure 4-38
├─SNMP Manager Configuration
| VM (View Manager) - Figure 4-66
| MM (Modify/Install Managers) - Figure 4-29
| RM (Remove Manager) - Figure 4-39
Figure 4-1. Overall System Command Organization
