D/I Mux III User’s Manual Appendix H. Set Report Options
283
Displaying New Port Expander Configuration
After all port expander configuration options are selected, the Alarm Dial Out screen displays
automatically. Each of the options set during configuration are reflected on the terminal screen,
with the Apply Changes “save” option included. If the displayed options are those desired, press
Y and [Enter] to save all configuration settings. If other changes are desired, press N and
[Enter], and all settings will remain as previously set.
Figure J-12 depicts the port expander configuration settings display screen.
16:49:38 ------------[ Alarm Dial Out ]---------- 11/30/96
Port Expander Present : Yes
NCC Port : 0
Port : 1
Attention String : 1t.r.o.P
Link String : L
Link Response : LINK ESTABLISHED
Unlink String : U
Unlink Response : UNLINK DONE
Apply Changes
Y) Yes
N) No
[Y/N] y
** Press Enter to Continue **
Figure I-12. Port Expander Configuration Settings Display Screen
