Page #142 background imageLoading...
Page #142 background image
Chapter 4. Configuration and Operation
122
DV - Displaying Smart AC Power Supply Parameters
Enter DV to Display the parameters of the 110 Volt Smart AC power supply (P/N 30308-102). Note that
the option to select DV is only available when a Smart AC power supply is installed in the D/I Mux III
system. Figure 4-21 depicts the DV screen.
] DV
10:03:19----------------- [ PS 1 : AC/DC ]----------------- 03/08/95
Minus 12V : -12.1 Plus 12V : 12.0
Minus 5V : - 5.0 Plus 5V : 5.0
Minus 48V : -48.4
SB Fuse : OK
Ringing Generator
-----------------
Voltage : 266.8 V[p-p]
Trip Margin : 83.0 V
Frequency : 20 Hz
Minor Alarm : Enabled
---Hardware--- Serial Software
Card Type Part Number Rev Number Revision
----------------------------------------------------------------------
AC/DC 30308-101 B 113611-0017 B 9/26/91
----------------------------------------------------------------------
Figure 4-21. Displaying the Smart AC Power Supply Parameters
