D/I Mux III User’s Manual Appendix H. Set Report Options
281
Feature Group 6.0/6.2 Screen Changes
The 6.0/6.2 Feature Group Current Mode status was labeled simply OFF.
Configuring the Port Expander
To configure the port expander, access the SO screen, and select P) Change Port Expander
Configuration from the options screen. The screen will ask “Do you have a port expander”.
Respond Y (Yes), or N (No), as appropriate.
The screen will then prompt for entry of the applicable Network Communications Controller (NCC)
control port connection, followed by the applicable port expander port number.
The next five entries specify the Port Expander Attention String, the Port Expander Link String,
the Port Expander Link Response, the Port Expander Unlink String, and the Port Expander Unlink
Response String. In each case, the default string command appears in the prompt brackets.
Coastcom recommends use of these default commands.
Figure J-11, on the following page, depicts the port expander configuration options screen.
