Chapter 5. Diagnostics
200
Performance
Enter PM to begin the Performance Monitoring sequence. This screen will only appear if a Facilities
Data Link Processor (FDLP) is installed in the multiplexer. Consult the FDLP User’s Manual for the
various options of the Performance Monitor screen, as depicted in Figure 5-28.
] PM
10:40:23---------- [ PERFORMANCE MONITOR ]----------- 03/08/96
Select Direction Select Side AT&T/ANSI
A) T1-1 D) User G) AT&T
B) T1-2 E) Network H) ANSI
C) Both F) Both I) Both
[ T1-1 ] [ User ] [ AT&T/ANSI T1-1 & None T1-2 ]
Screen Reports Clear Counters Printer Reports
0) Current Status 4) ESF Errors 6) ESF Error Counts
1) 1 Hour 5) Others 7) 1 Hour
2) 24 Hour 8) 24 Hour
3) ANSI 9) ANSI
Logging of Network Messages Network May Reset User Counters
L) Disable P) Disable
M) Enable With Data R) Enable
N) Enable Without Data [ T1-1 Enabled & T1-2 Enabled ]
[ T1-1 Disabled & T1-2 Disabled ]
S) Serial Port Setup
Q) Quit
Figure 5-28. Performance Monitor Screen
