Chapter 4. Configuration and Operation
110
] CL
Copy Line Card Configuration
Source Slot Number
[1..12] 1
Destination:
Slot Range
*) All Slots
[1..12] 2
Are You Sure?
Y) Yes
N) No
[Y/N]
Figure 4-8. Copying Line Card Configuration
In the example shown in Figure 4-8, the source slot number is the card configuration to be copied from
(slot 1), and the destination slot number (slot 2) receives the copied line card configuration.
WARNING!
DO NOT copy a single card configuration to more than 12 line cards at once or all line cards will be configured to
the same T1 channel. When configuring a 24-slot multiplexer, copy the configuration in two phases. Ensure that
only cards assigned to T1-1 are copied to other cards being used on T1-1. This applies to T1-2 cards also. DO
NOT mix T1-1 and T1-2 cards during the copy process.
Switching to another map, then returning to the working map, usually forces cards to resume normal
communications.
